Masi Vincere Tiagra
Details
Built around our X6 Disc aluminum frame and comfort-tuned geometry, the Vincere line features a taller, tapered head tube and a carbon bladed fork to produce the perfect all-day Grand Fondo bike. Shimano's 10 speed Tiagra derailleurs and shifters provide effortless and precise shifting. TRP Spyre-C disc brakes and Kenda Valkyrie 30c folding tires deliver excellent control and comfort for a variety of conditions.
- Vincere X6 Disc, butted alloy frame with smooth welds and tapered head tube
- Vincere Disc MC-7 carbon fork with tapered steer tube, flat-mount disc, and thru-axle
- 68mm threaded BSA bottom bracket
- Internal cable routing
- Hydraulic flat-mount disc brakes
- 12mm thru-axles
- 30c tires and clearance for tires up to 32c
Specs
| Frame | Vincere X6 Disc | double-butted alloy | smooth welded | 1.125 - 1.5" tapered head tube | 68mm threaded BSA bottom bracket | internal routing | flat-mount disc brake | replaceable derailleur hanger | 12x142mm thru-axle |
|---|---|
| Fork | Vincere Disc | MC-7 carbon | 1.125 - 1.5" tapered 7075 aluminum steer tube | flat-mount disc brake | 12x100mm thru-axle |
| Hubs | Brev M. Disc | Sealed bearings | Front: 12 x 100mm thru-axle, Rear: 12 x 142mm thru-axle | 6-Bolt | 28H |
| Tires | Kenda Valkyrie | 700 x 30c | Folding |
| Bottom Bracket | Shimano 68mm threaded BSA |
| Crankset | Shimano Tiagra FC-4600 | 50/34T chainring | 50cm: 165mm, 52cm: 170mm, 54 - 56cm: 172.5mm, 58 - 60cm: 175mm |
| Shifters | Shimano Tiagra ST-4700 |
| Front Derailleur | Shimano Tiagra FD-4700 | 31.8mm band-type |
| Rear Derailleur | Shimano Tiagra RD-4700GS |
| Cassette/Freewheel | Shimano CS-HG500 | 10-spd | 11-32T |
| Chain | KMC X10 |
| Brakes | TRP Spyre-C disc | Flat mount | Dual piston | 6-bolt rotors, 160mm |
| Brake Levers | Shimano Tiagra ST-4700 |
| Handlebars | Brev M. compact alloy endurance bend | 31.8mm | 120mm drop | 75mm reach | 50-52cm: 40cm, 54-56cm: 42cm, 58-60cm: 44cm |
| Tape/Grips | Masi Gripper Silicone Gel |
| Stem | Brev M. Endurance | 3D forged alloy | -7° drop | 50-52cm: 90mm, 54-56cm: 100mm, 58-60cm: 110mm |
| Headset | FSA 42E 1.5" tapered |
| Seatpost | Brev M. Alloy | 27.2mm x 330mm | 5mm offset |
| Saddle | Masi Endurance Comp |
| Pedals | Sold separately |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Matte Grey / 56cm | 691840412445 | 41244 | 210000020957 |
