Details
The Shift S3 29" is an excellent introduction to full suspension Trail riding. With its 1x transmission, the 29" Shift S3 offers smooth riding, increased control, and faster speed over rocks, roots, and bumps thanks to its bigger wheel size. Its X6 alloy frame with tapered head tube and 120mm of travel features a simple and efficient single pivot suspension design, which allows for an easy and low-cost maintenance. The Suntour Raidon XC air fork and rear shock package provides 120mm of travel while the new Shimano Deore 1x drive train with its 11-46T 10-speed cassette is matched to a Suntour Zeron 30T crankset for a wider gearing choice. Last but not least, efficient stopping is provided by a set of new Shimano MT-200 disc brakes complete with 180/160mm rotors.
Features
- Shift S X6 Aluminum single pivot frame, 120mm travel w/ 9mm Q/R rear dropouts
- Suntour Raidon-R rear shock
- Suntour Raidon-XC-LO-R fork, 120mm travel, air spring w/ lockout
- Suntour Zeron 1x Boost crankset, 30T
- New Deore RD-M5120 10-spd Shadow + rear derailleur
- New Deore M4100 10-spd, 11-46T cassette + shifter
- Shimano HB-TX505 hubs
- Shimano MT-200 Hydraulic disc brakeset
- Kenda Honey Badger 29x2.20" tires
Specs
Frame | Shift S X6 Aluminum series dual suspended Single Pivot frame | 29"x120mm travel | Tapered 1.5" head tube | 73mm threaded BSA | Enduro bearings | 9mm Q/R rear dropouts |
---|---|
Fork | SR Suntour Raidon-XC-LO-R-29.0 | 1.5" Tapered Aluminum steer | 120mm travel | air spring hydraulic lockout |
Headset | FPD DOZER-1160A-2 w/ 1.5" ACB bottom | For 44/56mm head tube | 8mm Top Cone |
Rear Shock | Suntour Raidon R | 190X51 |
Rims/Wheels | Pivit XD-260 Disc | 29" x 32h aluminum double wall |
Hubs | Shimano TX-505 aluminum | Center Lock Disc | cassette 32h |
Tires | Kenda Honey Badger | 29x2.20" | 30tpi |
Crankset | Suntour Zeron 1X AX-S-30 | 30T Steel Zig-Zag Chainring |
Bottom Bracket | Suntour BB-BKA008-C | 73mm, sealed cartridge |
Chain | KMC X10 NP/GY | Missing Link |
Rear Derailleur | New Shimano Deore RD-M5120 | 10-spd | Shadow Plus |
Cassette/Rear Cogs | New Shimano Deore CS-M4100-10 | 10-spd | 11-46T |
Shifters | New Shimano Deore SL-M4100-R 10-spd |
Handlebars | Pivit alloy 20mm riser bar 31.8mm | 700 / 720mm | 9 Deg. sweep |
Tape/Grips | WTB Weirwolf |
Stem | Pivit alloy Trail 0 Deg. | 4 bolts | Ext.: 60mm |
Brake Levers | Shimano BL-MT200 hydraulic |
Brakes | Shimano hydraulic BR-MT200 | 180/160mm Center Lock rotors |
Pedals | Sold separately |
Saddle | WTB Volt Sport w/ color accents |
Seat Post | Pivit alloy micro adjust 31.6mm | 350mm |
Accessories & Extras | Frame bearings by Enduro USA |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Vivid Blue / Medium | 691840114165 | 11416 | 210000021720 |
Vivid Blue / Large | 691840114172 | 11417 | 210000021721 |
